Powerful performance and flexibility
Built on a scalable system architecture. Designed to meet performance demands for all flash software-defined storage, VDI, and data analytics.
Technical Specifications
Processor
Two 2nd or 3rd Generation AMD EPYCTM Processors with up to 64 cores per processor
Memory
DDR4: Up to 32 x DDR4 RDIMM (2TB), LRDIMM (4TB), bandwidth up to 3200 MT/S
Storage
Front Bays:
● Up to 24 x 2.5” with up to 24 NVMe, SAS/SATA (SSD/HDD)
● Up to 12 x 3.5” SAS/SATA (HDD)
● Up to 16 x 2.5” SAS/SATA (SSD/HDD)
● The 24 x 2.5” SAS/SATA backplane won’t be available until April block
Rear Bays:
Up to 2 x 2.5” SAS/SATA (HDD/SSD)
Power Supplies
● 800W Platinum
● 1400W Platinum
● 2400W Platinum
Fans
● Standard/High Performance/Very High Performance
Hot Plug Fans
Dimensions
Height — 86.8mm (3.42”) • Width — 434.0mm (17.09”) • Depth — 736.29mm (28.99”) • Weight — 36.3KG (80lb)
Form Factor
2U rack server
Embedded Management
● iDRAC9
● iDRAC Direct
● iDRAC RESTful API with Redfish
● Quick Sync 2 BLE/wireless module
Bezel
Optional LCD bezel or security bezel
OpenManage Software
● OpenManage Enterprise
● OpenManage Enterprise Power Manager
● OpenManage Mobile
Integrations and Connections
OpenManage Integrations:
● BMC Truesight
● Microsoft System Center
● RedHat Ansible Modules
● VMware vCenter
OpenManage Connections
● IBM Tivoli Netcool/OMNIbus
● IBM Tivoli Network Manager IP Edition
● Micro Focus Operations Manager I
● Nagios Core
● Nagios XI
Security
● AMD Secure Encrypted Virtualization (SEV)
● AMD Secure Memory Encryption (SME)
● Cryptographically signed firmware
● Secure Boot
● Secure Erase
● Silicon Root of Trust
● System Lockdown (requires OpenManage Enterprise)
● TPM 1.2/2.0, TCM 2.0 optional
GPU Options
Up to three double wide 300W or six single wide 75W accelerators
Ports:
Front ports
● 1 x Dedicated iDRAC micro-USB
● 1 x USB 2.0
● 1 x VGA
Internal ports
● 1 x USB 2.0
Rear ports
● 1 x USB 2.0
● 1 x Serial (optional)
● 1 x VGA
● 1 x USB 3.0
● 1 x Ethernet
● 1 x Power Button
PCIe
Up to 8 x PCIe Gen4 slots
Network options
OCP x16 Mezz 3.0
Embedded NIC
2 x 1GE LOM
PCIe
Up to 8 x PCIe Gen4 slots
Operating System and Hypervisors
● Canonical Ubuntu Server LTS
● Microsoft Windows Server with Hyper-V
● Red Hat Enterprise Linux
● SUSE Linux Enterprise Server
● VMware ESXi
